1

Standard NC control system

臺灣新代/遠(yuǎn)杰定制

2

Maximum machining diameter

?32mm

3

Maximum machining length (1 time clamping)

310mm

4

Maximum travel without guide sleeve

60mm

5

Maximum diameter of drill hole on the end face of the main shaft

?11mm

6

Maximum drilling depth for the end face of the main shaftSpindle through hole diameter

50mm

7

Spindle through hole diameter

?34mm

.

8

Spindle rotation speed

8000rpm

9

Maximum tool diameter for rotating tool

?13mm

10

Maximum tool rotation speed

5500rpm

11

Maximum collet diameter of back spindle

?33mm

12

Maximum bore diameter of back spindle end face

?11mm

13

Back spindle rotation speed

6000rpm

14

Number of tool installationRow cutting tool for turning

24

15

Row cutting tool for turning

7

16

Side rotating tool

5

17

Front drilling tool

4

16

Backside drilling tool

4

17

Backside rotary tool

4

The serial number

Cutter size

18

Tool (turning tool)

?12mm*7+?16mm*1

19

Spindle spring chuck

STAR32

20

Guide bush

STAR32

21

Back spindle spring chuck

STAR32

22

Side rotating tool chuck

ER16*3+ER20*2

23

Chuck for drilling sleeve

ER16

The serial number

Fast feed speed

24

X1/Y1/Z1/X2/Z2

30m/min

25

Y2

24m/min

The serial number

The motor

26

Spindle motor

4.4kw

27

Rotating spindle motor

1.5kw

28

Back spindle motor

2.9kw

29

Axis motor

0.85kw

30

Center height

1050mm

31

The power capacity

16KVA

32

Air pressure required by a pneumatic device

0.6MPa

33

The machine weight

4050Kg

34

Overall dimension of the machine (length * width * height)

275*166*193cm

35

Mail volume

155L
