1

Optional control system

2

Maximum machining diameter

?20mm

3

There is a guide sleeve one-time clamping maximum processing length

Effective stroke 220mm

4

One-time maximum machining length without guide sleeve

50mm

5

Whether the guide sleeve switch function

Effective stroke of spline guide sleeve 220mm

Sleeve guide sleeve 100mm

No set of 50 mm

6

Maximum drilling depth for the end face of the main shaft

50mm

7

Spindle through hole diameter

?28mm

8

Spindle rotation speed

6000rpm

9

S1 Side rotation power head of spindle

1 Drive 5 insert and pull type end face power head hole ER16 power head, spindle plug and pull end face power head 1 drive 3 ER16

10

S2 back spindle tool

1 Drive 6 ER16 power cutter with fixed outer garden cutter holder and drill pipe

11

Maximum collet diameter of back spindleMaximum bore diameter of back spindle end face

?20mm

12

Maximum bore diameter of back spindle end face

?11mm

13

Number of tool installation

24

14

Row cutting tool for turning

7

15

Side rotating tool

5

16

Front drilling tool

4

17

Backside drilling tool

5

The serial number

Cutter size

17

Tool (turning tool)

¨12mm*6

18

Chuck, guide sleeve

19

Spindle spring chuck

STAR20

20

Guide bush

STAR20

21

Back spindle spring chuck

STAR20

22

Side rotating tool chuck

ER16*3

23

Chuck for drilling sleeve

ER16

The serial number

Fast feed speed

24

X1 Y1 Z1 X2 Z2

30m/min

25

Y2

24m/min

The serial number

The motor

26

Spindle motor

4.4kw

28

Rotary tool motor

1.5kw

29

Back spindle motor

2.9kw

30

Axis motor

850kw

31

Center height

1050mm

32

The power capacity

16kva

33

Air pressure required by a pneumatic device

0.6mpa

34

The machine weight

3400kg

35

Overall dimension of the machine (length * width * height)

275*132*193（cm）

36

volume

155L
