1

Standard NC control system

Taiwan's new generation of

2

Maximum machining diameter

?12mm

3

Maximum machining length (1 time clamping)

310mm

4

Maximum travel without guide sleeve

60mm

5

Maximum diameter of drill hole on the end face of the main shaft

?11mm

6

Maximum drilling depth for the end face of the main shaft

50mm

7

Spindle through hole diameter

?33mm

8

Spindle rotation speed

6000rpm

9

Maximum tool diameter for rotating tool

?11mm

10

Maximum tool rotation speedMaximum collet diameter of back spindle

5500rpm

11

Maximum collet diameter of back spindle

?32mm

12

Maximum bore diameter of back spindle end face

?11mm

13

Back spindle rotation speed

6000rpm

14

Number of tool installation

20

15

Row cutting tool for turning

7

16

Side rotating tool

5

17

Front drilling tool

4

16

Backside drilling tool

4

The serial number

Cutter size

17

Tool (turning tool)

?12mm*6+?16mm*1

18

Chuck, guide sleeve

19

Spindle spring chuck

STAR32

20

Guide bush

STAR32

21

Back spindle spring chuck

STAR32

22

Side rotating tool chuck

ER16*3+ER20*2

23

Chuck for drilling sleeve

ER16

The serial number

Fast feed speed

24

X1 Y 1 Z1 X2 Z2

30m/min

25

Y2

24m/min

The serial number

The motor

26

Spindle motor

27

Rotary tool motor

2.9kw

28

Axis motor

0.85kw

29

Center height

1050mm

30

The power capacity

16KVA

31

Air pressure required by a pneumatic device

0.6MPa

32

The machine weight

4050Kg

33

Overall dimension of the machine (length * width * height)

275*166*193cm

34

Tank volume

155L
